Straight Blade Snowplow
- Blade Width: 7'6" & 8'
- Fits: Truck Class 2, 3 & Tractors
- Moldboard: Stainless & Powder-Coated Steel
GET IT STRAIGHT & STAINLESS
The all-new PRO-PLOW 3 line of straight blade plows offers the first stainless steel straight blade model from Western Products. With limited moving parts and full hydraulic range of motion–these straight blade plows are workhorses that move snow efficiently season after season.
Compatible with Trucks & Tractors
Featured Accessories
10" Rubber Deflector
Control the snow and always see where you’re going with optional deflectors. Our 2-ply rubber snow deflectors include bolt-on steel plates to ensure proper positioning of the deflectors to keep your view clear and clean.
Part Number
Curb Guard (Pair)
Go right up to the edge with bolt-on curb guards. Protect the outer edge of your snow plow from wear when plowing along sidewalks and curbs. Made of cast metal, each curb guard effectively protects the outer edge of the plow.
Part Number
Shoe Kit
Protect your plow and the road, while extending the life of your cutting edge with an adjustable shoe kit. The cast iron construction and shape increases the surface contact area and helps glide over gravel and dirt at the correct height. Extending cutting edge and base angle life when plowing on rocky or abrasive surfaces.
Part Number
Product Specs
| Models | 93776 | 93773 | 93771 | 93768 |
|---|---|---|---|---|
| Blade Width | 7'6" | 7'6" | 8' | 8' |
| Blade Width | 2.29 m | 2.29 m | 2.44 m | 2.44 m |
| Moldboard Options | Stainless Steel | Powder-Coated | Stainless Steel | Powder-Coated |
| Moldboard Options | Stainless Steel | Powder-Coated | Stainless Steel | Powder-Coated |
| Blade Type | Straight Blade | Straight Blade | Straight Blade | Straight Blade |
| Blade Type | Straight Blade | Straight Blade | Straight Blade | Straight Blade |
| Vehicle Compatibility | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors |
| Vehicle Compatibility | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors | Truck Class 2 - 3 & Tractors |
| Approx. Weight* (Without Mount) | Stainless: 598 lbs | Powder-Coated: 581lbs | Stainless: 635 lbs | Powder-Coated: 617 lbs |
| Approx. Weight* (Without Mount) | Stainless: 271 kg | Powder-Coated: 264 kg | Stainless: 288 kg | Powder-Coated: 280 kg |
| Plowing Width (at 28-degrees) | 79.5" | 79.5" | 84.8" | 84.8" |
| Plowing Width (at 28-degrees) | 201.9 cm | 201.9 cm | 215.4 cm | 215.4 cm |
| Blade Height | 29" | 29" | 29" | 29" |
| Blade Height | 73.66 cm | 73.66 cm | 73.66 cm | 73.66 cm |
| Blade Thickness | 14 ga | 14 ga | 14 ga | 14 ga |
| Blade Thickness | 14 ga | 14 ga | 14 ga | 14 ga |
| Trip Springs | 2 | 2 | 2 | 2 |
| Trip Springs | 2 | 2 | 2 | 2 |
| Ribs | 8 | 8 | 8 | 8 |
| Ribs | 8 | 8 | 8 | 8 |
| Lift Cylinder (Single-Acting) | 1.5" x 8" | 1.5" x 8" | 1.5" x 8" | 1.5" x 8" |
| Lift Cylinder (Single-Acting) | 3.81 cm x 20.32 cm | 3.81 cm x 20.32 cm | 3.81 cm x 20.32 cm | 3.81 cm x 20.32 cm |
| Angling Rams (Single-Acting) | 1.5" x 10" | 1.5" x 10" | 1.5" x 10" | 1.5" x 10" |
| Angling Rams (Single-Acting) | 3.81 cm x 25.4 cm | 3.81 cm x 25.4 cm | 3.81 cm x 25.4 cm | 3.81 cm x 25.4 cm |
| Cutting Edge | ⅜" x 6" (Standard) | ⅜" x 6" (Standard) | ⅜" x 6" (Standard) | ⅜" x 6" (Standard) |
| Cutting Edge | 0.95 cm x 15.24 cm (Standard) | 0.95 cm x 15.24 cm (Standard) | 0.95 cm x 15.24 cm (Standard) | 0.95 cm x 15.24 cm (Standard) |
| Mount Type | UltraMount® 2 | UltraMount® 2 | UltraMount 2 | UltraMount 2 |
| Mount Type | UltraMount® 2 | UltraMount® 2 | UltraMount 2 | UltraMount 2 |
Product Literature & Support Manuals
Quick Match
Does This Plow Fit My Vehicle?
PRO-PLOW® 3 Photo Gallery
